Ayre’s Diamond output stage
Variable Gain Transimpedance (VGT) volume circuit
Ayre’s exclusive Equilock circuit
46 step volume control, each of 1.5 dB
Linear analog power supply
zero-feedback and fully-balanced discrete circuitry
High-speed circuit board material
Input ground switching for true source isolation
Six inputs: four balanced, two single-ended
Ayre Conditioner power line RFI filter
AyreLink communication system
Maximum Input Level
8 V rms – unbalanced inputs
16 V rms – balanced inputs
Gain
Gain Variable to match the required output level of the system without the need for attenuation.
Input Impedance
1 MΩ unbalanced inputs
2 MΩ balanced inputs (1 MΩ per phase)
XLR Input Polarity
Pin 1 = Ground
Pin 2 = Non-inverting (Positive)
Pin 3 = Inverting (Negative)
Frequency Response
DC – 250 kHz
Power Consumption
40 watts in operating mode
60 watts in operating mode (volume control active)
Dimensions
17.25″ W x 13.25″ D x 3.75″ H
(44cm x 34cm x 10cm)
Weight
23 pounds (10.5 kg)
