KEF
KEF Ci160.2C In-Ceiling Speaker
SELECT OPTIONS:
Please call our store to purchase:
904-642-6677
Ci160.2C
Ci-C Series offers an ideal introduction to the world of custom installation speakers. Featuring KEF's sophisticated 'sit anywhere' Uni-Q driver array, which places the tweeter in the acoustic centre of the bass/midrange cone, this allows both the tweeter and woofer to act as a single point source that disperses the sound widely and evenly throughout the room.
Weather resistant treatment protects the speakers from moisture and UV light. Ultra-Thin Bezels that are barely visible at the edge of exceptionally flat grilles mean the C Series fits unobtrusively into your home. Grille Off
Fast and Easy to Install
KEF's Ci loudspeaker design makes them so quick and easy to install that once the wire is run and the hole is cut in your wall or ceiling you can be listening to music in less than two minutes.
Key Features
- UTB™ Ultra-Thin Bezel
- 160mm (6.5in.) Uni-Q driver
- 16mm (0.6in.) Aluminium dome tweeter with tangerine waveguide
- Magnetic grille
- Paintable grille and bezel
- Weather Resistant
- IP64 Certified
| Model | Ci160.2CR |
| Nominal Impedance | 8Ω Ohm |
| Sensitivity | (2.83V/lm) 89dB |
| Frequency Response | 52Hz-20kHz (+/-6dB) open-backed |
| Crossover Frequency | 2.5kHz |
| Drive Units | LF: 160mm (6.5in.) HF: 16mm (0.6in.) |
| Recommended Amplifier | 10-100W |
| External Dimensions | Diameter: 234.6mm (9.24in.) Depth: 88.7mm (3.49in.) |
| Cut-Out Dimensions | Diameter: 196mm (7.71in.) |
| Mounting Depth from Surface | 84.5mm (3.33in.) |
| Weight | 1.4kg (3.1lbs) |
| Optional Rough in Frame | RIF160R |
| Optional Rear Enclosure | RNC160R |
| Model | Ci160.2CS |
| Nominal Impedance | 8Ω |
| Sensitivity (2.83V/ 1m) | 89dB |
| Frequency response (±6dB) open-backed |
52Hz-20kHz (+/-6dB) |
| Crossover frequency | 2.5kHz |
| Drive units LF HF |
160mm (6.5 in.) 16mm (.6 in.) Uni-Q |
| Recommended Amplifier Power | 10-100W |
| Product external dimensions | H x W x D: 223 x 223 x 88.7 mm (8.78 x 8.78 x 3.49 in.) |
| Cut-out dimensions | H x W: 194 x 194 mm (7.64 x 7.64 in.) |
| Net Weight | 1.2kg (2.7lbs) |
| Mounting depth from surface | 84.5mm (3.33in.) |
| Optional rough in frame | RIF160S |
| Optional rear enclosure | RNC 160S |
| Model | Ci160.2CL |
| Nominal Impedance | 8Ω |
| Sensitivity (2.83V/ 1m) | 89dB |
| Frequency response (±6dB) open-backed |
52Hz-20kHz (+/-6dB) |
| Crossover frequency | 2.5kHz |
| Drive units LF HF |
160mm (6.5 in.) 16mm (.6 in.) Uni-Q |
| Recommended Amplifier Power | 10-100W |
| Product external dimensions | H x W x D: 303 x 223 x 88.7 mm (11.93 x 8.78 x 3.49 in.) |
| Cut-out dimensions | H x W: 274 x 194 mm (10.79 x 7.64 in.) |
| Net Weight | 1.6kg (3.5lbs) |
| Mounting depth from surface | 84.5mm (3.33in.) |
| Optional rough in frame | RIF160L |
| Optional rear enclosure | RNC 160L |
** KEF reserves the right, in line with continuing research and development, to amend or change specifications. E&OE.**
