Acoustic Signature
Acoustic Signature MCX2 Moving-coil Cartridge
Precio habitual
$1,958.00
Precio habitual
Precio de venta
$1,958.00
Precio unitario
por
Los gastos de envío se calculan en la pantalla de pago.
No se pudo cargar la disponibilidad de retiro
CARTRIDGES MCX2
QUICK PROFILE
The The Acoustic Signature MCX2 is a modern moving-coil cartridge, manufactured according to the latest technologies – the optimal partner for our NEO tonearm series. A ‘nude’ elliptical stylus assuring precise tracking results, high-purity silver coils and a CNC-milled and resonance-optimized chassis developed according to the finite element design principle form the basis for a souvereign sounding cartridge.
AWARDS
OFFERINGS
FINISHES:
FEATURES:
- Modern MC cartridge with high-purity silver coils
- Resonance-optimized aluminum chassis
- Easy mounting
- Precise tracking due to nude elliptical stylus
- Suitable for medium to high mass tonearms
TECHNICAL DATA:
Cartridge system:
Moving-coil
Stylus type:
Nude elliptical
Coil material:
4N silver
Cartridge chassis:
Resonance-optimized aluminum chassis
Voltage output
(at 1 kHz, 5 cm/sec.):
0.55 mV
Channel balance at 1 kHz:
< 1.5 dB
Channel separation at 1 kHz:
> 21 dB
Compliance, dynamic, lateral:
15 µm/mN
Tracking force range:
2.1 to 2.5 g
Recommended tracking force:
2.3 g (23 mN)
Frequency range at -3 dB:
20-25,000 Hz
Frequency response 20-20,000 Hz:
± 2.5 dB
DC resistance:
7 Ω
Recommended load:
100 Ω
Cartidge weight:
12.2g
