ARCAM / Dual-Mono Integrated Amplifier
Fifty years, put to work.
An anniversary badge is nice. An amplifier built around independently supplied left and right channels is more interesting. The A50 Signature marks ARCAM’s fiftieth year with a dual-mono Class G design and 150 watts per channel into 8 ohms. It is aimed at listeners who want a substantial stereo without dividing the amplifier into several boxes.
The House of Stereo perspective
Where the A50 Signature fits.
The appeal is how much of a system it can anchor. MM and MC phono support accommodates a wider range of cartridges; HDMI eARC brings in the television; USB-C serves a digital source. Add a network player if you want dedicated Wi-Fi streaming. We will help you spend on the capabilities you actually need.
At a glance
A50 Signature specifications
Stereo 8-ohm power ratings: both channels driven, 20Hz–20kHz, 0.5% THD. Speaker impedance, room size and listening level all affect amplifier matching.
The anniversary story is inside the chassis.
The A50 Signature gives each channel its own amplifier module, transformer windings, regulation, reservoir capacitors, Class G lifter stage and output-stage heatsink. That is the substance behind the dual-mono description. It is not a claim that the chassis contains two entirely separate mains transformers.
Its ESS ES9039Q2M DAC sits alongside new volume-control and Class A MM/MC phono circuitry. The October 2026 owner’s manual confirms three RCA line inputs plus a balanced XLR pair, HDMI eARC/ARC, two coaxial inputs, one optical input and USB-C. The manual is also our reference for dimensions, weight and power consumption where ARCAM’s web table differs. Pair it with the CD25 over XLR or RCA, and add a network streamer if that is how you listen.
Full technical specifications
Manufacturer specifications. Power figures retain their load, bandwidth and channels-driven conditions. Regional mains versions and firmware-dependent features should be checked for your unit.
Continuous power output (0.5% THD), per channel
2 channels driven, 20Hz - 20kHz, 8Ω 150W
2 channels driven, 1kHz, 4Ω 220W
Harmonic distortion, 80% power, 8Ω at 1kHz 0.002%
Analogue Inputs
Number of inputs 3 (RCA pairs), 1 (XLR pair)
Signal/noise ratio (A-wtd, ref. 50W, 1V input) 106dB
Frequency response 20Hz—20kHz ± 0.2dB
Phono (MM) Input
Input impedance 47kΩ + 100pF
Frequency response (ref. RIAA curve) 20Hz—20kHz ± 1dB
Digital Inputs
1 × HDMI eARC/ARC; 2 × coaxial RCA; 1 × optical Toslink; 1 × USB-C.
Supported Sample Rates (kHz)
USB-C Only 384, 352.8, 192, 176.4, 96, 88.2, 48, 44.1
Other digital inputs 192, 176.4, 96, 88.2, 48, 44.1
Bit depths (bit) 32, 24, 16
Frequency response (filter 1) 20Hz—20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS) 110dB*
Headphone Output
Maximum output level (RMS) into 32Ω/300Ω 2.5V/5V
Load range 16Ω - 2kΩ
Wireless Specifications
Bluetooth Version - 5.4; A2DP Sink/Source, AVRCP, BLE, SBC, AAC, aptX, aptX HD and aptX Lossless, LE Audio, Auracast
Bluetooth Transmitter Frequency and Power - 2,400 MHz to 2,483.5 MHz: <20dBm
General
Mains voltage 100V or 110–120V or 220–240V, 50–60Hz
Power consumption (maximum) 800W*
Power consumption (standby) <0.5W
Dimensions W x D (including speaker terminals) x H (including feet) 431 x 344 x 99mm
Weight (net) 11kg
Weight (packed) 15.2kg
Supplied accessories
Mains lead(s)
Remote control with 2 x AAA batteries
Quick Start Guide
Important Safety Instructions
A50 Signature clarification: the October 2, 2026 owner’s manual lists XLR line input, 11kg net weight, 15.2kg packed weight and 800W maximum consumption (marked provisional in the manual). These take precedence here over the differing web summary. Asterisks retain the manufacturer’s provisional markings.
Manuals, setup guides and downloads
ARCAM product support and current downloads
External resources open in a new tab. Check the model and follow ARCAM’s instructions before installing firmware. Manuals may describe regional versions or features added through updates.
Press coverage
Publisher opinions are separate from House of Stereo’s advice. Review-era prices, software and specifications can differ from current information.
Darko.Audio — A50 Signature and CD25 announcement
Background on the anniversary designs. This is launch reporting, not a completed listening review.
A few useful answers
Can I order this online?
Please call House of Stereo at 904-642-6677 to order. We will confirm availability, system compatibility and delivery details with you.
Does it include Wi-Fi streaming?
Use a separate network streamer for dedicated Wi-Fi playback. Built-in Bluetooth serves compatible wireless sources; it is a different connection from a network streaming platform.
