Van den Hul

Van Den Hul's The MC Silver IT 65G Interconnects (RCA)

$1,223.00 USD
$1,223.00 USD
En oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

SELECT OPTIONS:

With the MC – SILVER IT 65 G all production handling is done with extreme care and maximum attention is paid to maintain a very constant characteristic impedance along the whole cable, as well as in the micro domain, to prevent signal reflections even up to very high frequencies.


--

This cable exhibits an extended frequency range up to 65 GigaHertz. It's a slimline version of our MC - SILVER IT Mk II 75 Ohm. With durable transparent cobalt blue HULLIFLEX®(*) jacket. Available in regular lengths.


  • The centre lead consists of 19 extreme high grade Matched Crystal (MC) extruded OFC strands with a very thick and dense extruded Matched Crystal (MC) purest silver coating applied in a mechanical processing step.

  • The diameter of this centre conductor is: 1.4 mm. and the cross-section area is 1.17 mm². The centre lead resistance is a remarkably low: 1.43 Ohm/100 m..

  • The typical capacitance is: 83 pF/meter.

  • The insulation between core and shielding is made of Teflon tape in several layers exhibiting a typically low relative dielectric constant of 1.4.

  • The double shielding is made of a 96 x 0.10 mm. Matched Crystal (MC) OFC wire braiding with a very thick and dense coating of very pure silver with underneath a helically overlapping wound very pure 2.5 x 0.05 mm. silver ribbon.

  • The external insulation is made of the special HULLIFLEX ® EHD material.
