Monitor Audio
Monitor Audio Cinergy 200
This product may take 3 to 5 business days to fulfill.
Couldn't load pickup availability
Like the rest of the Cinergy range, the 200 incorporates some very smart features to achieve its effortless performance.
Key Features:
- Unique isolation options
- Rotatable mid-tweeter array
- Removable port bungs
- Suited to custom-built mounting behind an acoustically transparent screen
- 1 x MPD Transducer
- 2 x 8" RDT Driver
- 2 x 2.5" C-CAM Driver
- Magnetic grilles
- THX® Certified
"It is a dynamic, thrilling listen that really gets the adrenaline pumping."
- StereoNET
True cinema sound at home
On the outside, handy brackets make installation easy. Inside, two mid-range drivers double the power handling, improve efficiency, and reduce reflections off ceilings and floors. Together, they ensure everything from the most epic cinematic score to the quietest whisper of dialogue is reproduced beautifully and faithfully.
Spotlight: Majik House
Monitor Audio shines a spotlight on smart home technology experts Majik House, focusing on The Annexe, an immersive cinema Cinergy demonstration suite that utilises Monitor Audio's Cinergy speaker system, showing their clients what's achievable in a high-end home cinema.
Specifications
Category |
Details |
|---|---|
| THX Certification | THX® Certified Ultra |
| System Format | 3 Way |
| Sensitivity (2.83 Vrms @ 1 M) | 90 dB |
| Maximum Linear SPL** (@1m, free space)** | Continuous 109 dB, Peak 122 dB |
| Power Handling (RMS) | Continuous 350 W, Peak* 1400 W |
| Nominal Impedance | 4 Ohms |
| Minimum Impedance (20 Hz - 20 kHz) | 3.8 Ohms |
| Recommended Low Frequency Crossover Frequency | 80 – 100 Hz (High Pass) |
| Recommended Amp Requirements (RMS) | 200 – 1400 W (IA750-2 or IA750-4) |
| Bass Alignment | Ported** |
| Port Tuning Frequency | 47 Hz** |
| LF Extension, In Wall, With Port Bungs (-6 dB) | 47 Hz |
| LF Extension, In Free Space, No Port Bungs (-6 dB) | 47 Hz |
| HF Extension (-6 dB) | >30 kHz |
| Drive Unit Complement |
2 x 8" RDT Driver 2 x 2.5" C-CAM Driver 1 x MPD Transducer |
| External Dimensions (Cabinet Only, H x W x D) | 904 x 300 x 160 mm (359/16 x 1113/16 x 65/16") |
| External Dimensions (Inc Grille, H x W x D) | 904 x 300 x 173.6 mm (359/16 x 1113/16 x 613/16") |
| Max External Dimensions (Inc all Fittings, H x W x D) | 904 x 300 x 173.6 mm (359/16 x 1113/16 x 613/16") |
| Weight | 30 kg (66 lb) |
| Conditions |
Calculated from a peak voltage, this is not a true power figure but useful for comparisons When used in an In-Wall or On-Wall configuration it is recommended to use the fitted port bungs to control bass output. This will effectively make the product a sealed box. Band limited with Low pass at 200 Hz, should only be used with IA800-2C and the correct speaker profile. Tested with a music-like noise signal with distortion and power compression remaining below audible limits. |
| THX |
THX® Certified Loudspeakers. THX® and the THX® Logo are the property of THX® Ltd., registered in the U.S. and other countries. |
| Warranty | Lifetime |
Transparent Design Philosophy
At Monitor Audio we believe the ultimate loudspeaker is one capable of producing sound as laid down by the artist so accurately that it becomes transparent. The physical design should be sympathetic to any environment and work in harmony with the desire for transparency. Cinergy was created as a result of this Transparent Design Philosophy, and is engineered to ‘disappear’ into your home cinema, allowing you to experience the visceral thrill of the very pinnacle of movie sound, without distraction.
THX® Certified Ultra
THX is the gold standard for audio and visual fidelity: a globally recognised mark assuring Cinergy delivers the ultimate home cinema experience. It’s not simply a set of measurements done on a computer or in a lab; THX certification is only achieved using the dynamics of real-world listening, so you can have the utmost confidence that Cinergy will deliver a breathtakingly realistic home cinema experience.
Midrange drivers
The midrange drivers do a lot of the heavy lifting in any movie-focused system; these frequencies contain a lot of the dialogue and atmospherics that make films so engaging. That’s why the Cinergy midrange drivers use cutting-edge Monitor Audio acoustic technologies to ensure they deliver pristine performance, including RDT II cones, for the required dexterity. The midrange drivers also sits within a mid-pod driver array that can be rotated to allow any speaker in the range to be positioned either vertically or horizontally.
-
MPD II
Our Micro Pleated Diaphragm II (MPD II) technology ensures Cinergy’s high-frequency transducers deliver accurate, lifelike sound without any distortion. The wider, smoother, more focused soundstage it creates is exactly what you need for totally engaging movie sound.
-
Mid Pod
Cinergy’s mid-pod driver array can be rotated to allow any speaker in the range to be positioned either vertically or horizontally. This flexible approach makes system creation a breeze, ensuring the perfect set-up for your cinema space.
-
RDT II
Rigid Diaphragm Technology II uses a ‘sandwich’ of ultra-thin, low-mass skins bonded to a honeycomb Nomex® core, making our bass drivers both exceptionally strong and lightweight. This combination allows them to deliver both the incredibly dynamic and the wonderfully delicate with breath-taking dexterity.
Bass drivers
Bass is vital to cinematic sound. That’s obviously the case with the deep, powerful low end delivered by dedicated subwoofers, but upper bass is also a vital ingredient, providing as it does the link between low-end rumble and the midrange. Cinergy’s powerful, dexterous bass drivers utilise RDT II technology to ensure they match perfectly with the midrange drivers, while also being able to punch above their weight in terms of low-end power.
Your cinema, your way
The best home cinemas are purpose-built from the ground up, enabling you to create a completely bespoke experience all of your own. Cinergy gives your installer the creative flexibility to design and build a cinema that exactly meets your requirements. Modular designs, bespoke isolation options, clever fixing methods and a range of versatile, high-performance loudspeakers combine to provide an experience that’s perfectly attuned to your chosen space.
-
In-Wall
For the most discreet high-performance system imaginable you can locate Cinergy completely within the walls of your home cinema installation. It’s even possible to crate a ‘sound wall’ behind your screen for the last-word in concentrated power.
-
On-Wall
If a completely installed cinema isn’t an option, you’ll be pleased to hear Cinergy performs equally as well positioned on-wall. That’s why we have made sure our Cinergy speakers look as good as they sound, and offer grilles if required.
-
Freestanding
The Cinergy 300 is not only the largest speaker in the range, it’s also the most versatile in that it can be used as a freestanding model. This enhances system building flexibility, allowing you to partner it with other models in the range used on-wall or in-wall.
Rotation.
Your home is like no one else’s. Fortunately, Cinergy is designed to adapt to every possible scenario. For example, the mid-tweeter array on the Cinergy 100, 200 and 300 easily rotate, depending on whether you’d prefer it to be a vertical or horizontal install. So there’s no need to compromise on your design vision when you’re searching for the perfect sound.
Small details.
Because small details make a big difference, our audio engineers have developed a range of practical isolation accessories for Cinergy. L-shaped bracket isolators and 3-layer silicone feet isolators reduce vibrations by up to 18dB, and ensure optimal performance. These small differences, have a big impact on your enjoyment.
