Ortofon
Ortofon SPU Classic N
Regular price
$1,037.99
Regular price
Sale price
$1,037.99
Unit price
per
Shipping calculated at checkout.
This product cannot be sold online.Please call our store to purchase:
904-642-6677
The SPU Classic N provides the same sound reproduction properties as the SPU Classic GM series
SPU Classic N
The SPU Classic N is a Moving Coil (MC) cartridge with an 18µm spherical stylus profile sold without an integrated headshell unit. Those with vintage SPU-type headshells can use the Classic N to recreate an authentic and functional SPU cartridge.
Listeners who wish to mount the SPU Classic on a traditional headshell may do so by using the SPU N adaptor.
NB: Vintage SPU-type headshells are no longer available.
Specifications
Channel balance at 1 kHz
1 dB
Output voltage at 1 kHz, 5cm/sec
0.2 mV
Channel separation at 1 kHz
20 dB
Frequency response 20 Hz - 20 kHz
3 dB
Tracking ability at 315 Hz
60 µm
Compliance, dynamic, lateral
8 µm/mN
Stylus type
Nude Spherical
Stylus tip radius
R 18 µm
Tracking force range
3.0-5.0 g (30-50 mN)
Tracking force, recommended
4.0 g (40 mN)
Tracking angle
20°
Internal impedance, DC resistance
2.0 ohm
Recommended load impedance
10 ohm
Coil wire material
High Purity Copper (OFC)
Cartridge colour
Black matte
Cartridge weight
13 g
