OTTA Theorbo Moving Coil Phono Cartridge
OTTA Theorbo Moving Coil Phono Cartridge
Deliveries over $700 - Signature Required!
No se pudo cargar la disponibilidad de retiro
A closer connection to the performance
The OTTA Theorbo is the step up from the Mandolin, combining a Micro-Ridge diamond with a ruby cantilever and black sandalwood body. OTTA voices it for rich vocals, natural tonal color, and an expansive presentation, keeping musical expression at the center of its design.
Micro-Ridge stylus and precision coils
Theorbo uses a specially wound square 6N OCC coil and a samarium-cobalt magnetic system. An aluminum motor cover helps control resonance. Each completed cartridge undergoes measurements and a listening evaluation.
Mandolin or Theorbo?
Theorbo replaces the Mandolin’s elliptical stylus with a Micro-Ridge profile and uses different electrical and mechanical specifications. Your tonearm and phono stage should guide the choice alongside your listening priorities.
Specifications
| Type | Low-output stereo moving coil |
|---|---|
| Body | Black sandalwood |
| Cantilever | Ruby |
| Weight | 8.4 g |
| Vertical tracking angle | 20° |
| Recommended load | 100–470 Ω |
| Tracking force | 1.5–2.0 g; 1.8 g recommended |
| Recommended tonearm | Medium mass |
| Stylus | Micro-Ridge diamond |
| Output | 0.38 mV at 3.54 cm/s |
| Coil | Square 6N OCC; special winding |
| Internal impedance | 8.6 Ω |
| Frequency response | 15 Hz–30 kHz (±3 dB) |
| Channel balance | <0.02 dB at 1 kHz |
| Channel separation | >28 dB at 1 kHz |
| Dynamic compliance | 16 μm/mN |
| Tracking ability | 80 μm at 315 Hz / 2 g |
| Suggested break-in | 35 hours |
Plan your setup with House of Stereo
Theorbo requires amplification suitable for a low-output moving coil cartridge. Contact House of Stereo with your turntable, tonearm, and phono stage models for help with system matching. Careful alignment, tracking force, and loading are essential to getting the best from your cartridge.
Available to order. Ships directly to you from our distribution partner.
