ARCAM / 9-Channel Class G AV Amplifier
Cinema with the stereo taken seriously.
The AVA35 brings Class G amplification to ARCAM’s nine-channel theater platform. With 16-channel processing, it can anchor an ambitious immersive system while leaving room for external amplifiers as the layout grows. It is a strong candidate when music listening matters just as much as what happens when the lights go down.
The House of Stereo perspective
Where the AVA35 fits.
A theater receiver cannot rescue an incoherent speaker plan. We will help you decide which channels need amplification, how the subwoofers will work together and where calibration can help. The AVA35 supplies the processing and connections; getting those decisions right is what turns equipment into a convincing room.
At a glance
AVA35 specifications
Powered channels and processing channels are different. Larger layouts require additional power amplifiers. Power ratings vary with impedance and the number of channels driven; ask us to compare like-for-like ratings.
Class G and flexible channel assignment.
The AVA35 combines nine Class G amplifier channels with sixteen-channel processing and matrix channel assignment. That flexibility is useful when external amplifiers enter the system: outputs can be assigned around the actual layout rather than forcing the layout around a fixed set of amplifier roles. ARCAM limits subwoofer assignment to channels 4 and 11–16.
It supports Dolby Atmos, DTS:X, IMAX Enhanced and AURO-3D, with seven HDMI inputs and three outputs. The sixteen preamplifier outputs are RCA, not balanced XLR. For an all-separates system with balanced outputs, look at the AVP45. ARCAM specifies 145 watts into 8 ohms with two channels driven across the audio band, and 110 watts with seven channels driven at 1kHz.
Plan the channels before buying the boxes
Dirac Live room correction is included in the platform; Bass Control and Active Room Treatment are upgrade options requiring the appropriate licences. The measurement microphone and 5m USB cable are listed among the supplied accessories. Follow the linked guide for microphone calibration and measurement positions.
An immersive layout needs the right combination of processing channels, power-amplifier channels and powered subwoofers. Send us the intended layout, speaker models, room dimensions and existing equipment. We can check the channel map, amplification, HDMI sources and ventilation before an installation becomes an expensive puzzle.
Radia AV Control, Spotify Connect, Tidal Connect, Qobuz Connect, AirPlay, Google Cast and Roon Ready are listed by ARCAM. Network playback and the coaxial and optical inputs have different format limits; see the specifications rather than assuming every socket accepts the same signal.
Full technical specifications
Manufacturer specifications. Power figures retain their load, bandwidth and channels-driven conditions. Regional mains versions and firmware-dependent features should be checked for your unit.
Decoding / Encoding
Maximum Channel Count: 16
Reassignable Channels:
All channels (Subwoofers into CH4 & 11-16 only)
Supported Decoding and Encoding:
Dolby Atmos, Dolby TrueHD, Dolby Atmos Height Virtualisation, Dolby Surround
DTS:X, DTS HD Master, DTS Neural:X, DTS Virtual:X
MPEG H
IMAX Enhanced
AURO-3D, AURO-2D
HDMI
Inputs/Outputs: 7/3 (Zone 1 outputs = 2, Zone 2 outputs = 1)
HDMI/HDCP Versions: 2.1a/2.3
Resolution support (resolution/framerate):
Up to 8K/60Hz or 4K/120Hz
Supported Dynamic Range Profiles:
HDR, HDR10, HDR10+, HDR10+ Gaming, Dolby Vision, HLG
Supported HDMI features:
Variable Refresh Rate (VRR), Auto Low Latency Mode (ALLM), CEC, eARC/ARC (Zone 1, Output 1) On Screen Display
Streaming
Works with (apps):
ARCAM Radia AV Control, Spotify Connect, Tidal Connect, Qobuz Connect, Roon (Ready)
Works with (services):
Apple Airplay, Google Cast, Internet Radio, Podcasts, UPnP
Supported Hi-res media:
FLAC, WAV (LPCM), AAC, ALAC, AIFF, MP3, OGG
Gapless Playback Supported
Supported Hi-res Bit depth: 16, 24
Supported samples rates (kHz): Up to 192 kHz
Frequency response: 20Hz—20kHz ± 0.05dB
Digital Inputs
Number of inputs (Coaxial/Toslink): 2/2
Supported Sample Rates (kHz):
Coaxial (RCA): 192, 176.4, 96, 88.2, 48, 44.1
Optical (Toslink): 96, 88.2, 48, 44.1
Bit depths (bit) (Coaxial/Toslink): 24, 16
Frequency response: 20Hz—20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS): 100dB
Analogue Inputs
Number of inputs: 3 (RCA pairs)
Signal/noise ratio (A-wtd, ref. 50W, 1V input): 100dB
Frequency response: 20Hz—20kHz ± 0.2dB
Preamplifier Outputs
Number of Outputs RCA/XLR: 16/0
Single-ended (RCA) peak output level per channel: 2V RMS
THD+N (20 Hz to 20 kHz): –100dB
Amplification
Amplifier Channels: 9, Class G
Continuous power output (0.5% THD)
8Ω, 20Hz - 20kHz, 2 channels driven: 145W
4Ω, 1kHz, 2 channels driven: 200W
8Ω, 1kHz, 7 channels driven: 110W
4Ω, 1kHz, 7 channels driven: 130W
Harmonic distortion @80% power, 8Ω at 1kHz: 0.004%
General
Mains voltage (V/Hz): 100–120V or 220–240V, 50–60Hz
Max Power consumption: 900W
Max Thermal dissipation: 3070 BTU/hour
Idle Power consumption: 93W
Idle Thermal dissipation: 320 BTU/hour
Standby Power consumption (Default/Low Power): 2W/0.4W
Dimensions W x D (including speaker terminals) x H (including feet): W432 x D459.1 x H170mm
Weight (net): 22.7kg
Weight (packed): 29.4kg
Supplied accessories:
Region Specific Power Cord(s)
Rear panel cowl
Remote control with 2 x AAA batteries
Measurement Microphone
5m USB Cable
Quick Start Guide
Important Safety Instructions
Wireless Specifications
Bluetooth Version: 5.4
Bluetooth Profiles: A2DP Sink/Source, AVRCP, Snapdragon Sound, AAC, LE Audio, Auracast, GATT, VCP, MCP, BAP, CAP
Bluetooth Transmitter Frequency Range and Power:
2,402 MHz to 2,480 MHz <Max 10.73dBm
Wi-Fi Network: IEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi Transmitter Frequency Range and Power:
2.400 GHz to 2.4835 GHz < Max 17.4dBm
5G Wi-Fi Transmitter Frequency Range and Power:
5.15-5.35GHz, 5.47-5.725GHz, 5.725-5.875GHz, < Max 19.26dBm
Manuals, setup guides and downloads
- AVA35 Latest SW Release Notes
- Control Protocols
- Control4 Module
- Crestron Home Module
- Crestron Module
- Dirac Live Quick Start Guide & Supporting Files
- ELAN Module
- EU declaration of conformity
- Owner's Manual
- RTI Module
- Specification Sheet
- URC Module
ARCAM product support and current downloads
External resources open in a new tab. Check the model and follow ARCAM’s instructions before installing firmware. Manuals may describe regional versions or features added through updates.
Press coverage
Publisher opinions are separate from House of Stereo’s advice. Review-era prices, software and specifications can differ from current information.
Audioholics — Radia AV range announcement
Launch coverage of the range and its architecture, not a hands-on performance review. Early release schedules may differ from current availability.
A few useful answers
Can I order this online?
Please call House of Stereo at 904-642-6677 to order. We will confirm availability, system compatibility and delivery details with you.
Can you help plan the system?
Yes. Tell us which speakers you own, your room dimensions, listening distance and source components. We can work through connections, amplifier matching and setup before you order.
