NAD PP 2e Phono Preamplifier

NAD PP 2e Phono Preamplifier

$299.00 USD
$299.00 USD
Sale Sold out
Shipping calculated at checkout.
Shipping Deliveries over $700 - Signature Required!
View full details

PP 2e

PHONO PREAMPLIFIER

The NAD PP 2e Phono Preamplifier delivers low-noise and wide-band amplification for MM and MC cartridges, helping records sound open and detailed. Its carefully engineered RIAA stage supports a well-balanced presentation across diverse pressings, bringing greater clarity to systems with basic or absent phono inputs. An external 24-volt supply helps maintain stable performance, while gold-plated sockets ensure reliable long-term connection to your turntable and amplifier. With Auto Power Down and a compact footprint, the PP 2e offers a simple, musical upgrade to any vinyl system.

KEY FEATURES

  • Low-noise, wide-band phono stage for clear vinyl playback
  • Supports MM and MC cartridges for broad turntable compatibility
  • Precision RIAA equalisation for accurate tonal balance
  • External 24-volt power supply for stable, quiet operation
  • Gold-plated input sockets for reliable signal transfer
  • Compact design suitable for modern hi-fi setups
  • Auto Power Down feature for energy-efficient use
  • Line-level output for easy integration with amplifiers and receivers
  • High-quality components used throughout the signal path
  • LED power indicator for simple operational status

PRODUCT STORY

Clear, Low-Noise Phono Performance

The PP 2e provides a low-noise gain stage for both moving-magnet and moving-coil cartridges, helping vinyl playback sound clean and engaging. Its precision RIAA equalisation preserves tonal accuracy from track to track, allowing the music’s character to come through naturally. A gentle infrasonic filter helps reduce unwanted rumble, supporting smooth, stable playback.

Designed for Flexible System Integration

The PP 2e supports a wide range of cartridges and uses a straightforward line-level output to pair easily with modern amplifiers and receivers. The external 24-volt power supply contributes to quiet, consistent performance, while gold-plated input sockets ensure a secure electricalc onnection. These features make it simple to add dedicated phono capability to systems that lack a built-in phono stage.

Compact Design with Thoughtful Power Management

Auto Power Down reduces energy consumption by switching the PP 2e into standby when it’s not in use. Its compact form fits neatly alongside typical turntable setups without requiring extra shelf space. These practical details make the PP 2e an easy addition to a wide range of vinyl systems.

SPECIFICATIONS

MC

Input Impedance (R and C) 100 Ohm + 180pF
Gain at 1kHz 60dB
Input Sensitivity (ref. 200mV output) 0.3mV
Signal to Noise Ratio 78dB (A weighted, with cartridge connected)
Input Overload (20Hz/1kHz/20kHz) 0.8/9/84mV
Rated Distortion (THD 20Hz - 20kHz) <0.03%
RIAA Response Accuracy ±0.3dB

MM

Input Impedance (R and C) 47 kilohm + 200pF
Gain at 1kHz 35dB
Input sensitivity (ref. 200mV output) 2.5mV
Signal to Noise Ratio 80dB (A weighted, with cartridge connected)
Input overload (20Hz/1kHz/20kHz) 10/102/950mV
Rated Distortion (THD 20Hz - 20kHz) <0.03%
RIAA response accuracy ±0.3dB

Line Out

Output Impedance 100 Ohm
Maximum Output Level 5.3V

General Specifications

AC Supply External 23.5V DC
Dimensions excl. Power supply (W x H x D) 135 x 49 x 72mm 5 5/16 x 1 15/16 x 2 7/8"
