T+A

T+A PA 2500 R Integrated Amplifier - Store Demo

Regular price $8,500.00 USD
Regular price $14,670.00 USD Sale price $8,500.00 USD
Sale Sold out
Shipping calculated at checkout.

SELECT OPTIONS:

PA 2500 R

Integrated Amplifier


The Integrated Amplifier

Twice as tall, higher output power and even more connection facilities – the PA 2500 R exceeds the specification of the PA 2000 R in many areas, but its character in terms of sound quality is in no way inferior to its smaller sibling. This by no means goes without saying, because very powerful amplifiers often forfeit the finer points of dynamics and detail tracery. Our PA 2500 R integrated amplifier circumvents this danger: its basic circuit is the same as that of the PA 2000 R, and even the circuit board layouts are identical. However, its heat-sinks are twice the size, and the case accommodates two of our new high-performance mains power supply units, with the result that it can deliver more than 280 Watts of continuous power per channel into 4 Ohms loudspeakers. The amplifier is therefore effortlessly capable of controlling speakers which are extremely critical in terms of phase and impedance. The PA 2500 is even more powerful than the smaller machine, but retains exactly the same dynamism and cultured sound.



Power supply

The quality of any output stage is determined to a very great extent by the mains power supply as well as the circuit topology. Mains power supply units must be as stable and resilient as possible, to ensure that the voltage they generate does not collapse even when very high peaks are encountered. In conventional equipment this requires very large transformers, but the limited space available in the low-profile R-series machines spurred on our en­gineers to develop an ingenious alternative solution: a regulated high-frequency sine-wave mains power supply with generous reservoir capacity, capable of delivering up to 1200 Watts without problem. The mains power supply can deliver very large quantities of current extremely quickly, even when the gradient of the peak signals is steep. Our experience in building amplifiers over a period of thirty years has taught us the importance of the quality of audiophile modules for the final outcome in terms of sound quality, and that is why we choose our components with great care and then select them according to strict criteria, to ensure optimum characteristics for each specific application.


Connections

We use low-loss mica capacitors with silver electrodes, zero-induction resistors, precision low-noise audio resistors, and nickel-free gold- or rhodium plated terminals specially manufactured for T+A. Many of these components were developed for military applications, and therefore fulfil exacting requirements in terms of quality and durability. Another in-house development for the latest R-series is a completely new and very fast data bus for data exchange between the devices, which makes it possible to control a whole system with a single remote control handset. Alternatively, if the system includes an MP 2000 R, the equipment can be controlled using the T+A App for iOS or Android. Both amplifiers are equipped with a sophisticated protective circuit which is situated outside the signal path, and therefore cannot possibly have any adverse effect on sound quality. The protective circuit constantly compares the input signal before the output stage with the output signal, and instantaneously switches off the output relays if it detects the slightest deviation (clipping, distortion, etc.). The protective circuit is also triggered if overheating occurs, or if a short-circuit is present at the outputs. All the electronic circuitry for controlling the machines is recessed into the solid aluminum front profile, where the shielding effect is outstanding. The front panel features a bright, dimmable screen (VFD) and control knobs with variable lighting.



REVIEW & AWARDS

T+A PA 2500 R/MP 2000 R/G 2000 R - Read More

"I can already hear the outcry. Peace? What’s he talking about? Music is meant to be exciting! We want stimulation not tranquility! How can this writer praise peace above all else? That’s insane! And yet, that’s exactly what I’m doing."



T+A PA 2500 R and G 2000 R - Read More

"In the PA 2500 R integrated amplifier and the G 2000 R record player T+A has created two components that combine solid build, flawless operation and exceptional sound quality. They made sure the amplifier is as flexible as possible, with the option to correct small, room acoustic related problems. The numerous inputs and the available output power make the amplifier a real all-rounder, one that proved capable with both large (costly) and small (more affordable) loudspeakers. The record player is very easy to install, there are no silly adjustments, put down the LP, lower the arm and enjoy the music. T+A seems to know how to push my ‘like’ button with products that are so well thought out. All of which makes it inevitable that T+A is never going to be the cheapest. These are examples of craftsmanship and German Grundlichkeit (thoroughness) that promise years of reliability, and for that there will always be a reward and a price."



T+A elektroakustik PA 2500 R integrated amplifier and MP 2000 R MKII media player - Read More

"During my factory tour I developed a great admiration for the efforts of the T+A staff and the top-notch gear they were producing. I was certainly prepared to like the R-Series but really no more than any review subject that comes my way—in that sense I’m always an optimist. However, the PA 2500 R and MP 2000 R exceeded my expectations by a wide margin. Even though they can be purchased individually, I consider them an inseparable partnership, completing each other’s thoughts like identical twins would. In other words, wunderbar!"



Sound Stage 2/2022 - Read More

"T+A MP 2500 R and PA 2500 R
The T+A gear never lost its composure on anything I played through it. Whether at concert volume or quiet evening listening levels the character and presentation remained absolutely consistent, stable and musically expressive."


The Absolute Sound 3/2020 Editor´s Choice

"The highboy integrated amp in T+A’s vaunted R series, the 140Wpc PA 2500 R is a dual-mono, fully balanced, high-voltage design with a Class AB output stage biased into Class A for the first 20–25 watts. Clean and authoritative, and easy to operate, the PA 2500 R conveys the sense of a well-oiled machine. Its sonic signature is one of balance and control, with musical images rooted in space and vocals models of stability. Its most identifiable traits are wideband spectral response and dynamic extroversion.
The PA 2500 R delivers big, high-intensity wattage that never seems to waver in responsiveness and extension regardless of load. Includes an excellent phonostage. Wunderbar!"


Test T+A PA 2500 R – so baut man Vollverstärker - Read More

"Man kennt den offen-präzisen Klang von T+A Verstärkern. Doch der T+A PA 2500 R zelebriert diese Art der Wiedergabe auf eine nochmals überzeugendere Art. Der große Vollverstärker ist trotz Schaltnetzteil einer der überzeugendsten Vollverstärker unterhalb 10.000 Euro."



The absolute sound 9/2017 - Read More

"However, the PA 2500 R and MP 2000 R exceeded my expectations by a wide margin. Even though they can be purchased individually, I consider them an iseparable partnership, compleating each other´s thoughts like identical twins would. In other words, wunderbar!"


mactechnews.de 2/2017 - Read More

"Leistung satt

Die Herforder Audio-Ingenieure haben nicht nur mit dem PA 2500 R HiFi-Komponenten im Angebot, die es mit der stärksten Konkurrenz aus aller Welt aufnehmen kann und dabei im Preis/Leistungsverhältnis ganz ausgezeichnet dastehen. – „Made in Germany“ wie aus dem Lehrbuch!"


Fidelity 26 07-08/2016 - Read More

"Endlich Ruhe

Tonmeisterliche Qualitäten mit einer Spur Glanz und Gewalt. Dank technischer Brillanz und umfangreicher Luxusausstattung ein Allroundverstärker, wie er im HiFi-Buche steht. Einen PA 2500 R würde ich ohne jede Einschränkung auch als Verstärker im Mastering-Studio einsetzen!

Haben die Komponenten der R-Serie von T+A das Zeug zur idealen Anlage? Unbedingt! Ihren großen Geschwistern klanglich dicht auf den Fersen, spielen PA 2500 R, MP 2000 R und G 2000 R mit den meisten teuren High End-Komponenten locker auf Augenhöhe, ersparen dem Besitzer aber deren übliche Befindlichkeiten. Sie laufen einfach. Endlich Ruhe für Musik."


stereo 8/2015

"Überaus kraftvoller, zudem superb ausgestatteter Vollverstärker der Spitzenklasse mit ausgesprochen musikalischem, körperhaftem Auftritt.

Das Klangbild des Herforder Gespanns ist denn auch keine Überraschung, denn es ist von ausgesprochen eleganter Akkuratesse. Während der Plattenspieler als exquisite Quelle die musikalischen Häppchen reicht und dabei seine hohe Klasse unter Beweis stellt, feinste Details aus den Tiefen der Rillen zu holen, dient der potente Vollverstärker PA 2500 R als eine Art Durchlauferhitzer. Er bereitet die Musik auf und reichert sie gewinnbringend mit ungehäurer Kraft und Autorität an.

Klangniveau: 93%
Preis / Leistung: Exzellent"



stereoplay 7/2015 - Read More

"An sich ist dieser T+A-Auftritt die Untertreibung des Jahres. Unter dem unscheinbaren Alukleid steckt ein Hammer-Verstärker, der keine Konkurenz zu scheuen braucht. Leistung und Klang im Überfluss, verbunden mit höchstem Komfort.

Nach einiger Zeit hat man dann entspannt verinnerlicht, wie dieser Vollverstärker eigentlich arbeitet: nämlich als weit offenes Tor tief in die Musik hinein.

Klang: absolute Spitzenklasse
Gesamturteil: sehr gut
Preis/Leistung: überragend"




SPECIFICATIONS

Pre-amplifier stage

Frequency response + 0 / − 3 dB 0,5 Hz – 300 kHz
Signal / noise ratio, unweighted / A-weighted 105 / 109 dB
Total harmonic distortion/Intermodulation < 0,001 % / < 0,001 %
Channel separation > 90 dB
Loudness Switchable, variable to suit loudspeaker efficiency
Tone controls
Bass
Treble
Switchable, channel-separate
−6 … +8 dB
−6 … +8 dB
Nominal input sensitivity
High level (RCA) 4 × 250 mV … 4 Veff/20 kOhms
Balanced (XLR) 3 × 500 mV … 8 Veff/5 kOhms
Phono-MM (optional*)
*Phono module replaces one high-level input
1 – 5 mV,
16 Capacitances
Phono-MC (optional*)
*Phono module replaces one high-level input
60 – 1000 µV,
16 Impedances

Outputs


Headphone 50 Ohms
PRE out RCA Nom 1 Veff, Max 9,5 Veff, 75 Ohms

PRE out XLR
Nom 1,45 Veff, Max 19,6 Veff, 75 Ohms

Output stage


Nominal output per channel into 8 Ohms 140 Watts
into 4 Ohms 280 Watts
into 2 Ohms 560 Watts
Frequency response + 0/– 3 dB 1 Hz – 150 kHz
Slew rate 60 V/µs
Damping factor > 65
Total harmonic distortion < 0,02 %
Reservoir capacity 120000 µF

Mains / Accessories / Dimensions


Control interface R2-Link
Remote control SRC 1
Mains connection 100 – 120 V or 200 – 240 V, 50 – 60 Hz
Max. 2000 Watt
Standby < 0,5 W
Additional features Trigger input +5V … 20V via adapter plug for remote power-on
Input 3 (symmetrical) or 5 (asymmetrical) can be configured as Surround Pass Through
Optional Accessories PHE-P/PA R MM or MC phono content_default | Power Three HD (Carbon) | Power Bar | Audio Quad (Carbon) | Speaker Hex (Carbon)
Dimensions (W x H x D)/Weight 16,5 × 46 × 40,5 cm / 14,5 kg
Finishes Silver anodised aluminium (43), black anodised aluminium (42), brushed

Technical modifications reserved
